Description
The vertical orientation allows multiple columns to be cast in a single mold, maximizing the use of the molding box and reducing the "metal-to-sand" ratio. This pattern ensures per...
The vertical orientation allows multiple columns to be cast in a single mold, maximizing the use of the molding box and reducing the "metal-to-sand" ratio. This pattern ensures perfectly straight columns with consistent wall thickness, featuring a bottom-up gating system that prevents air pockets and ensures a high-density, defect-free metal structure.
Specifications
| Attribute | Value |
|---|---|
| Pattern Material | High-Grade Cast Iron (CI) / Steel-Reinforced Aluminium |
| Pattern Layout | Vertical Multi-Cavity (Optimized for Floor Space) |
| Component Type | Industrial Support Columns / Pillar Bases |
| Molding Process | High-Pressure Automatic Molding / Vertical Flaskless |
| Dimensional Accuracy | ISO 8062 CT7 to CT9 (High Consistency) |
| Additional Information | |
|---|---|
| SKU | 1 |
| Country of Origin | India |
| Customisable | No |
Application
This pattern is the industry standard for producing Industrial Bench Pillars and Support Columns used in factory shop floors. It is widely utilized for casting Architectural Lamp Posts and Decorative Railing Pillars for urban infrastructure projects. In the machine tool sector, it is used for Drilling Machine Columns and Lathe Leg Supports.
Trade Details
| Production Lead Time | 8-14 Days |
| Available Stock | In stock |
| Sample Availability | No |
Shipping & Logistics
| Shipping Internationally | Yes | |
| Methods |
| |
| IncoTerms |
| |
| Port of Dispatch | -- | |
| Packaging Type | -- | |
| Units per Package | -- | |
| Barcode / HSN / GTIN / UPC | -- | |
| Dispatch Lead time | Ships in 7 Days |
Company Profile
₹1 Crore – ₹5 Crore
Factory Details
Main Markets
Frequently Asked Questions
Why use Cast Iron for the pattern instead of Aluminium or Wood?
For high-volume production (millions of cycles), Cast Iron is superior. It is much harder than aluminium, meaning the "sand abrasion" won't wear down the dimensions of the pattern over time. This maintains the High-Precision of the columns for many years.
How does the "Vertical" layout improve casting quality?
Vertical casting allows for Laminar Flow from the bottom to the top. As the metal rises, air and impurities are pushed upward into the "Risers," leaving the main column body dense, strong, and free of blowholes or slag.
Is this pattern compatible with DISA or other vertical molding machines?
Yes. This pattern is specifically designed to meet the requirements of Vertical Flaskless Molding Lines. The draft angles and plate thickness are precisely calibrated for instant sand release at high speeds.
How do you prevent the columns from bending during cooling?
Since columns are long and thin, they can warp. Our pattern design includes Balanced Gating, which ensures the metal cools evenly on all sides. We also calculate the "Counter-Camber" if the design is prone to cooling-related distortion.
Can we cast different heights using the same multi-cavity pattern?
Yes. We can provide Block-off Inserts or "Adjustable Stopper" parts for the pattern. This allows the foundry to shorten the column length without needing to build a completely separate tool.
Cast Iron (CI) Multi-Cavity Vertical Column Pattern
The Cast Iron (CI) Multi-Cavity Vertical Column Pattern is a heavy-duty production tool designed for foundries focusing on architectural and industrial structural components.
