CNAF Jointing sheets S.AF-150
High-performance compressed non-asbestos jointing sheet (S.AF-150) made from fiber/NBR composite. Offers excellent stress retention, temperature and chemical resistance, ideal for industrial sealing under moderate pressure and heat.
- FOB PriceNA
- Min Order QuantityNA
- Payment TermsCredit Card,Cash,Cheque,Demand Draft,Online
 made from fiber/NBR composite. Offers excellent stress retention, temperature and chemical resistance, ideal for industrial sealing under moderate pressure and heat.
)
Other Details
The S.AF‑150 CNAF Jointing Sheet is designed for applications requiring reliable industrial sealing under fluctuating temperatures and pressures. Manufactured from non-asbestos fiber reinforced with NBR, it offers excellent dimensional stability, stress relaxation, and resistance to water, steam, oils, and chemicals. Optional graphite facing enhances sealing performance in high-temperature/pressure environments.
Product Application
Ideal for sealing in chemical plants, steam systems, water pipelines, oil & gas, and general industrial equipment requiring non-asbestos gasketing.
Technical Specifications
-
Compressibility (ASTM F36): ~9 %
-
Recovery: ~55 %
-
Stress Relaxation: 50 MPa, 16 h/175 °C → 39 MPa; 50 MPa, 16 h/300 °C → 35 MPa
-
Density: ~1.8 g/cm³
-
Leak Rate: < 0.05 mg×s⁻¹×m⁻¹ (DIN 28090‑2)
-
Temperature range: Up to ~450 °C depending on binder
