Attal Gaskets

Other Details

CAF and Non-Asbestos Cut Gaskets are manufactured from premium jointing sheets such as compressed asbestos fiber, non-asbestos fiber, or rubber-bound sheets. These gaskets are widely used in various industries due to their superior sealing properties and resistance to high pressure and temperature.

We manufacture these gaskets in die-cut or hand-cut forms based on standard ANSI B16.21 or as per customer-provided drawings/specifications.

These gaskets are compatible with a wide range of media including:

• Steam, water, and gas

• Petroleum and hydrocarbons

• Solvents and distillates

• Alkaline solutions and alcohols

• Nitric, sulfuric, and hydrochloric acids (hot and cold)

Commonly used in:

• Heat Exchangers

• Pumps and Valves

• Pressure Vessels

• Engines and Industrial Pipelines

Product Application

• Automotive Engines & Machinery

• Steam & Gas Pipelines

• Oil & Petroleum Industry

• Chemical Plants

• HVAC and Utility Systems

• Boilers and Heat Exchangers

Technical Specifications

• Material: CAF / Non-Asbestos / Graphite / Rubber Jointing Sheets

• Standard Compliance: ANSI B16.21

• Thickness Range: 0.5 mm to 6 mm

• Max Operating Temperature: Up to 400°C

• Pressure Range: Up to 100 bar (depending on material type)

• Manufacturing Type: Die-cut / Hand-cut / CNC precision cut

• Size Range: Customizable as per drawing

• Automotive Engines & Machinery

• Steam & Gas Pipelines

• Oil & Petroleum Industry

• Chemical Plants

• HVAC and Utility Systems

• Boilers and Heat Exchangers
