- Reverse pulse-jet dust collectors
- Bag-filter cleaning systems
- Cartridge-filter cleaning systems
- Envelope-filter installations
- Ceramic-filter cleaning
- Sintered metal-fibre filters
- Cement and mineral-processing plants
- Woodworking dust-extraction systems
- Pharmaceutical and chemical plants
IN₹
Description
Dust Collector Solenoid Valve is an electrically actuated diaphragm pulse valve designed for cleaning filter elements in industrial dust-collection systems. Its springless diaphragm construction has only one primary moving component, enabling fast ON/OFF operation, efficient compressed-air usage, and a strong air pulse that dislodges dust from filter bags and cartridges. The valve has a pressure die-cast aluminium body and bonnet with a reinforced NBR, neoprene, or polyurethane diaphragm. Standard models support temperatures up to 80°C, while high-temperature variants with a Viton diaphragm and seat can handle up to 125°C. General-purpose, waterproof, and flameproof solenoid coils are available with multiple AC and DC voltage options.
Specifications
| Key Attributes | |
|---|---|
| Valve Type | Diaphragm pulse valve |
| Product Name | Dust Collector Solenoid Valve |
| Port Size Range | ¾–1½ inches |
| Body Material | Pressure die-cast aluminium |
| Bonnet Material | Pressure die-cast aluminium |
| High-Temperature Diaphragm | Viton |
| Listed Pressure | Up to 10 bar |
| Additional Information | |
|---|---|
| Brand | FLOMAX |
| Country of Origin | India |
Application
Trade Details
| Available Stock | In Stock |
| Sample Availability | Yes - paid |
Payment Terms
| Payment Methods |
|
Shipping & Logistics
| Shipping Internationally | No | |
| Methods |
|
Company Profile
Flow-Tech Enterprise, Tamil Nadu
Tamil Nadu, India
Tamil Nadu, India9 yrs
Wholesaler•Retailer•Manufacturer•Trading Company•Importer•Distributor
Turn Over
₹1 Crore – ₹5 Crore
Factory Details
Factory Size1000-5000 sqm
Main Markets
India
Frequently Asked Questions
1
1. What type of actuator is used in this valve?
The valve uses an electromagnetic solenoid actuator that receives an electrical signal to initiate rapid diaphragm opening and closing.
2
2. How does the valve clean dust-collector filters?
It releases a short, high-speed pulse of compressed air that creates a shockwave through the filter, dislodging accumulated dust from its surface.
3
3. Which filter types can be cleaned using this valve?
It is suitable for bag, cartridge, envelope, ceramic, and sintered metal-fibre filters used in reverse pulse-jet systems.
4
4. What temperature can the valve handle?
Standard models can operate at temperatures up to 80°C. Versions fitted with a Viton diaphragm and Viton seat can handle temperatures up to 125°C.
5
5. Which solenoid coils and voltages are available?
General-purpose IP20, waterproof IP65, and flameproof coil options are available. Voltage options include 24V, 110V, and 220V AC, as well as 12V, 24V, 110V, and 220V DC.
Dust Collector Solenoid Valve
Dust Collector Solenoid Valve is a fast-acting diaphragm pulse valve designed for reverse pulse-jet cleaning of industrial dust-collector filters. Its solenoid actuator enables rapid opening and closing, helping produce the compressed-air shockwave required to remove accumulated dust.
Min. Order Quantity: 1 piece
Shipping
Shipping fee and delivery date to be negotiated. Contact supplier now for more details.
