Description
The SS316 Butterfly Valve is designed for efficient flow regulation and tight shut-off across industrial piping systems. Its streamlined, rust-resistant stainless steel disc minimises friction and pressure loss, while the replaceable EPDM seat provides reliable sealing for different compatible media. The lightweight aluminium die-cast body, long-neck construction and lever operation enable convenient handling and installation. Featuring an ISO 5211 mounting flange, the valve can also be fitted with an actuator for automated operation. Its bidirectional, zero-leakage design provides dependable performance with low maintenance and a long service life.
Specifications
| Key Attributes | |
|---|---|
| Product Type | Butterfly Valve |
| Listed Valve Size | 24 mm |
| Available Size Range | 2 to 8 Inches |
| Body Material | Aluminium Die-Cast |
| Disc Material | SS304 or SS316 |
| Seat Material | EPDM |
| O-Ring Material | EPDM |
| Bearing | Metal-Backed PTFE |
| Maximum Pressure | Up to 14 Bar |
| Operation | Manual |
| Operator | Lever |
| Media Temperature | Medium Temperature |
| Suitable Media | Fuel, Water, Air, Gas, Powders and Solids |
| Flow Direction | Bidirectional |
| Shut-Off Performance | Zero Leakage |
| Additional Information | |
|---|---|
| Country of Origin | India |
Application
Company Profile
Flow-Tech Enterprise, Tamil Nadu
9 yrs
Wholesaler•Retailer•Manufacturer•Trading Company•Importer•Distributor
Turn Over
₹1 Crore – ₹5 Crore
Factory Details
Factory Size1000-5000 sqm
Main Markets
India
Frequently Asked Questions
1
1. Which media can this valve handle?
It is suitable for compatible fuel, water, air, gas, powders and solid materials.
2
2. What is the maximum pressure rating?
The valve can handle pressures of up to 14 bar.
3
3. Does the valve provide bidirectional flow control?
Yes. It supports bidirectional operation and provides a tight, zero-leakage shut-off.
4
4. Can this manually operated valve be automated?
Yes. The ISO 5211 mounting flange enables an actuator to be assembled on the valve.
5
5. Can the EPDM seat be replaced?
Yes. The EPDM seat is replaceable, which simplifies maintenance and helps extend the valve’s service life.
SS316 Ball Valves Coimbatore
Manually operated SS316 butterfly valve designed for reliable isolation and flow control of fuel, water, air, gas, powders and solids. It offers bidirectional operation, zero leakage, low operating torque and a replaceable EPDM seat.
