Description

An AHU VFD Panel for HVAC Air Handling Unit Control is an electrical automation panel used to manage and regulate the operation of air handling units in heating, ventilation, and air conditioning systems. It incorporates a Variable Frequency Drive (VFD) to control the speed of supply air and return air fan motors according to ventilation and cooling requirements. The panel may include circuit breakers, contactors, overload protection devices, control switches, sensors, and monitoring components based on the system configuration. It enables adjustable fan speed, controlled airflow, and automated operation through compatible thermostats, pressure sensors, or building management systems. By matching fan speed with actual airflow demand, it can help optimize energy consumption and improve HVAC operating efficiency. AHU VFD panels are suitable for commercial buildings, hospitals, hotels, offices, shopping complexes, and industrial HVAC installations.

Specifications

Key Attributes
AHU TypeHorizontal Blow-Through
Coil TypeDX (Direct Expansion)
Casing ConstructionDouble Skin (Sandwich Panel)
Fan TypeCentrifugal (Belt Driven)
Filter ClassG4 (Coarse)

Application

  1. HVAC air handling unit control
  2. Supply air fan speed regulation
  3. Return air fan control
  4. Commercial building ventilation systems
  5. Hospital and healthcare facility HVAC
  6. Industrial air conditioning systems
  7. Shopping malls and office complexes
  8. Hotel and institutional ventilation
  9. Cleanroom and controlled-environment HVAC systems
  10. Building automation and climate control


Company Profile

POWER LINE TRADERS
POWER LINE TRADERS, Tamil Nadu
TruCertified
IndiaTamil Nadu, India
22 yrs
Manufacturer
Factory Details
Factory SizeBelow 1000 sqm
Contract ManufacturingSub-Contractor
Frequently Asked Questions
1
What is an AHU VFD Panel?

An AHU VFD Panel is an electrical control panel that uses a variable frequency drive to regulate the speed of air handling unit fan motors.

2
What is the main function of an AHU VFD Panel?

Its main function is to control fan speed and regulate airflow according to HVAC system requirements.

3
How does a VFD improve AHU operation?

A VFD adjusts motor speed based on airflow demand, helping provide better control and potentially reduce energy consumption.

AHU VFD Panel for HVAC air handling unit control

An AHU VFD Panel is an electrical control panel designed to regulate the speed of air handling unit motors using a Variable Frequency Drive (VFD) for efficient airflow and HVAC system operation.

Min. Order Quantity: 1 piece

Shipping

Shipping fee and delivery date to be negotiated. Contact supplier now for more details.
