Description

The CV2 90 Degree Flat Top Chain Conveyor Curve is a specialized conveyor component developed for automated pallet transportation and directional transfer operations. It uses an accumulated flat top chain as its conveying medium and operates through a three-phase motor drive. The system supports pallet widths and lengths between 160 mm and 800 mm, with nominal operating speeds of 6, 9, 12, 15, and 18 m/min. It has a maximum load capacity of 90 kg and operates on a 220/380V AC power supply at 50 Hz. Motor mounting is available in L, R, and M configurations, with mounting directions of 0°, 90°, 180°, and 270°. The motor connection is provided through a terminal box.

Specifications

Key Attributes
Conveyor mediumAccumulated Flat Top Chain
Pallet width in transport direction /mm160, 240, 320, 400, 480, 640, 800 (160≤Bwt≤800)
Pallet length in transport direction /mm160, 240, 320, 400, 480, 640, 800 (160≤Bwt≤800)
Nominal speed /(m/min)6, 9, 12, 15, 18
Max. Load /kg90
Drive method3 phase motor
Motor mounting methodL, R, M
Motor mounting direction0°, 90°, 180°, 270°
Voltage /V220/380 AC
Frequency /Hz50
Motor connectionTerminal box
Additional Information
SKU1
Country of OriginIndia

Application

  1. 90-degree conveyor direction-changing operations.
  2. Curved pallet transportation systems.
  3. Automated conveyor line connections.
  4. Material transfer between perpendicular conveyor lines.
  5. Pallet handling in accumulated conveyor systems.
  6. Industrial conveyor layout optimization.
  7. Automated production line transportation.

Trade Details

Available StockIn Stock
Sample AvailabilityNo

Payment Terms

Payment Terms
  • Cash on Delivery (COD, if applicable)
Payment Methods
  • credit
  • cash
  • cheque
  • demandDraft
  • paypal

Shipping & Logistics

Shipping InternationallyNo
Methods
  • Road
IncoTerms
  • FOB

Company Profile

Muveera Engineering Equipments
Muveera Engineering Equipments, Tamil Nadu
TruBasic
IndiaTamil Nadu, India
Manufacturer
Factory Details
Factory Size1000-5000 sqm
Annual Production Capacity0
Frequently Asked Questions
1
What are the dimensions of the CV2/90 Degree Flat Top Chain Conveyor Curve?

The dimensions may vary based on specific configurations and requirements. Please refer to the technical specifications sheet available in our product details or contact customer service for precise measurements.

2
What is the maximum load capacity of this conveyor curve?

The maximum load capacity depends on various factors, including the belt type and application settings. Generally, it can carry loads of up to X pounds (please check detailed specs for exact numbers).

3
What types of industries typically use the CV2/90 Degree Flat Top Chain Conveyor Curve?

This conveyor curve is commonly used in industries such as manufacturing, packaging, food processing, and logistics where space-saving solutions and efficient material handling are necessary.

4
Can I customize the conveyor curve to fit my specific operational needs?

Yes! The CV2/90 Degree Flat Top Chain Conveyor Curve can be customized regarding length, width, height, and other features based on your operational requirements. Please consult with our sales team for customization options.

5
What payment methods do you accept for purchasing this product?

'We accept various payment methods including credit cards, cash, cheques, demand drafts, and PayPal. You can choose any of these options during checkout.'

SKU: 1

CV2/90 Degree Flat Top Chain Conveyor Curve

Designed for industrial material handling, the CV2 90 Degree Conveyor Curve enables smooth directional pallet movement. It features flexible motor mounting options, multiple speed settings, and a reliable flat top chain conveying mechanism.

Min. Order Quantity: 1 unit

Shipping

Shipping fee and delivery date to be negotiated. Contact supplier now for more details.
