A 220KV ACDB for Extra High Voltage Power Distribution is an electrical power distribution and switching system intended for use in extra-high-voltage substations and large-scale power networks. It supports the management of electrical power flow, circuit switching, isolation, monitoring, and protection in 220 kV installations. Depending on the equipment configuration, the system may incorporate high-voltage circuit breakers, disconnectors, current transformers, voltage transformers, surge arresters, busbars, and numerical protection relays. These components work together to support reliable power system operation and help isolate electrical faults through suitable protection arrangements. It is suitable for utility substations, power transmission networks, generating stations, and large industrial power infrastructure. Equipment selection and configuration depend on rated voltage, current capacity, insulation level, short-circuit withstand capability, environmental conditions, and app...
A 220KV ACDB for Extra High Voltage Power Distribution is an electrical power distribution and switching system intended for use in extra-high-voltage substations and large-scale power networks. It supports the management of electrical power flow, circuit switching, isolation, monitoring, and protection in 220 kV installations. Depending on the equipment configuration, the system may incorporate high-voltage circuit breakers, disconnectors, current transformers, voltage transformers, surge arresters, busbars, and numerical protection relays. These components work together to support reliable power system operation and help isolate electrical faults through suitable protection arrangements. It is suitable for utility substations, power transmission networks, generating stations, and large industrial power infrastructure. Equipment selection and configuration depend on rated voltage, current capacity, insulation level, short-circuit withstand capability, environmental conditions, and applicable electrical standards.

Specifications

Key Attributes
Rated Voltage Class11 kV / 33 kV dual rated
Short-Time Withstand Current25 kA
Panel Construction TypeMetal-enclosed (AIS)
Circuit Breaker TypeVacuum (VCB)

Application

  1. Extra-high-voltage power transmission substations
  2. Utility power distribution networks
  3. Power generation and grid interconnection facilities
  4. Large industrial electrical substations
  5. High-voltage transformer switching systems
  6. Electrical power transmission infrastructure
  7. Grid protection and monitoring systems
  8. Renewable energy grid integration substations
  9. Large-scale infrastructure power networks
