The barge board flashing serves as a critical weatherproofing component along the exposed edges of modern pitched roofs. Manufactured by precision-bending pre-painted metallic sheets into custom angled profiles, the trim effectively covers open roof gaps to direct water runoff away from internal wooden rafters and side wall cladding. The outer protective coating guards the underlying metal substrate against rust, color fading, atmospheric pollution, and moisture ingress. Precise edge crimping and overlapping designs ensure maximum structural stability against high wind shear forces during heavy storms. Easy handling, customizable dimensions, and seamless color matching with main roofing sheets make it an indispensable trimming detail for residential, agricultural, and industrial roof constructions.
| Key Attributes | |
|---|---|
| Substrate Material | Pre-Painted Galvanized Iron / Galvalume / Aluminum |
| Thickness Range | 0.40mm to 0.70mm |
| Surface Coating | Polyester / PVDF Paint Finish |
| Standard Girth / Width | 300mm to 450mm Developed Girth |
| Angle / Bend | 90 Degrees Standard Angle |
| Standard Length | 2.5 Meters to 3.0 Meters |
| Profile Design | Flanged L-Shape / Apex Bending Profile |
| Additional Information | |
|---|---|
| Country of Origin | India |
Seals verge and gable roof edges on industrial factory buildings and warehouse facilities.
Protects exposed timber barge boards and rafters on residential houses, villas, and cabins.
Prevents wind uplift and water entry on agricultural barns, livestock shelters, and storage sheds.
Covers side roof junctions on commercial shopping centers, offices, and prefabricated structures.
Provides a clean finished edge for carports, garages, and domestic outbuilding roofs.
| Available Stock | In Stock |
| Sample Availability | No |
| Payment Terms |
|
| Payment Methods |
|
Tamil Nadu, IndiaA barge board flashing is an angled metal trim fitted along the gable end of a roof to seal the joint between the roofing panels and wall structures.
It prevents heavy wind from lifting the roof edges, blocks rainwater from seeping into internal wooden structures, and keeps birds or pests out.
Yes, flashings are manufactured using pre-painted galvanized steel or galvalume coils to match or contrast seamlessly with the main roof color.
They are secured directly to the roofing sheets and barge boards using self-drilling screws fitted with weatherproof EPDM rubber washers.
Standard installation guidelines recommend an overlap of at least 100mm to 150mm between flashing sections to ensure a watertight seal.
Shipping fee and delivery date to be negotiated. Contact supplier now for more details.
