Description

Heavy-duty industrial hydraulic cylinders represent the core linear actuators of fluid-power systems, engineered to convert hydraulic fluid pressure into immense, controlled mechanical force. Manufactured from precision-honed steel tubing and high-tensile alloy steel piston rods treated with a thick hard-chrome plating, these cylinders resist wear, scoring, and side-load deflection. The high-performance polyurethane seal kits prevent internal oil bypass and external leakage under extreme pressure spikes and demanding duty cycles. Produced under rigorous dimensional and quality standards, each cylinder guarantees smooth stroke motion, reliable sealing, and long service life. It serves as an essential mechanical asset for hydraulic press builders, material handling equipment manufacturers, and mobile crane engineers. Ultimately, this advanced hydraulic cylinder delivers exceptional power density, precise motion control, and rugged durability.

Specifications

Key Attributes
Cylinder Diameter1000 mm
Stroke Length3000 mm
Working Pressure210 bar nominal working pressure (up to 350 bar peak pressure limit)
CertificationsISO
Material TypeStKM-13 precision honed steel tube with hard chrome-plated piston rod
Cylinder Dimensions100 mm bore diameter x 70 mm rod diameter x 800 mm stroke length
Output Force Capacity165 kN pushing force at 210 bar working pressure
Additional Information
SKU00006
Country of OriginIndia

Application

Serves as the primary linear actuator for heavy industrial hydraulic presses and metal forming machines.

Lifts and tilts heavy loads on mobile construction machinery, excavators, and dump trucks.

Operates scissor lift tables, loading dock platforms, and material elevation systems.

Controls clamping and sliding mechanisms on large automated manufacturing assembly lines.

Actuates hydraulic steering and lifting booms on industrial cranes and material handlers.

Upgrades pneumatic cylinders into high-force hydraulic motion control systems.

Trade Details

Production Lead Time4-7 Days
Available StockIn Stock
Sample AvailabilityNo

Payment Terms

Payment Terms
  • Custom Terms (manual entry)
Payment Methods
  • credit
  • cash
  • others

Shipping & Logistics

Shipping InternationallyUpon Request
Methods
  • Road
IncoTerms
  • FOB
Dispatch Lead timeShips in 1 Days

Company Profile

SRK ENGINEERING
SRK ENGINEERING, Tamil Nadu
TruBasic
IndiaTamil Nadu, India
7 yrs
Manufacturer
Turn Over

₹25 Lakhs – ₹1 Crore

Factory Details
Contract ManufacturingOEM Service
Main Markets
India
Frequently Asked Questions
1
What primary materials are used to construct this industrial hydraulic cylinder?

It is built using precision-honed steel tubing for the body barrel and high-tensile alloy steel with a hard chrome-plated finish for the piston rod.

2
What is the standard operating pressure rating for this hydraulic cylinder?

It is engineered for a nominal working pressure of 210 bar, with peak pressure handling capabilities up to 350 bar.

3
How is internal fluid leakage prevented between the piston and cylinder wall?

It utilizes high-performance multi-lip polyurethane piston seals and wear rings that maintain a tight seal under high pressure.

4
What mounting configurations are available for installing the cylinder?

It supports versatile installation styles including clevis mounts, front/rear flanges, trunnions, and foot brackets.

5
How does the hard chrome plating protect the piston rod from damage?

The hard chrome plating provides a hard, smooth, corrosion-resistant surface that protects against rust, stone chips, and seal-destroying scratches.

SKU: 00006

Heavy-Duty Industrial Hydraulic Cylinder

Heavy-duty industrial hydraulic cylinders offer a high-pressure, linear force generation solution designed for lifting, pushing, pulling, and precise motion control in heavy machinery. Engineered for continuous high-load operations, this robust hydraulic actuator ensures reliable power transmission and structural stability across industrial manufacturing and mobile equipment.

Min. Order Quantity: 1 piece

Shipping

Shipping fee and delivery date to be negotiated. Contact supplier now for more details.

Shipping InternationallyUpon Request
Estimated Delivery5 - 8 business days
