Features: LED displays air temperature and humidity, pointer shows instrument voltage and current; The production and inspection in line with the GB/T 24689.1-2009 plant protection machinery standards; Use optical, electric, and numerical control technologies, compatible with ATCSP plant diseases and pests inspection and prevention system; Auto-on in the daytime and auto-off at night. Nighttime working status is not affected by instantaneous intense light ; Use far-infrared light to process pest bodies rapidly (no poison bottle); Insect chamber has an auto rotation system with gear drive, which ensures separate insect samples collected in 8 different time periods; Rain control device can automatically manipulate the work of the whole lamp according to rainfall change; Drainage device can effectively separate the insects from the rain;
Technical parameters:
|
Light trap |
20 w black light lamp (main wavelength 365 nm) |
|
Lamp body material |
GB32080-92 stainless steel structure, in accordance with GB/T4237 |
|
Lamp support material |
GB3280-80 stainless steel |
|
Lamp dimension |
650 mm×650 mm×1900 mm |
|
Power supply |
DC 24 V; 24 V 100 W solar panels, 24 V 38 AH storage battery |
|
Power consumption |
Standby no more than 5 W, total power consumption no more than 300 W |
|
Startup time |
within 5 s |
|
Temperature control of far-infrared insect pest chamber |
85 ± 5 ℃ after 15 min of operation, processing time is adjustable (15 choices) |
|
Insulation resistance |
≥ 2.5 MΩ, with a leakage protection device |
|
Far-infrared insect body treatment |
The fatality rate is no less than 98%, integrality of insect body is no less than 95% |
|
Hitting screen size |
the two hitting screens are with an Angle of 120 degrees, 595 ± 2 mm long, 213 ± 2 mm wide, 5 mm thick |
|
Design life |
≥ 5 years |
ORIGIN: CHINA
