Description

The Granite Block Weighing System supports weight measurement for granite blocks at quarries, stone processing facilities, storage yards, and dispatch locations. Its ready-to-use configuration is intended to simplify weighing before transportation and help operators determine the quantity of granite loaded onto each truck. Available sizes and capacities can be selected according to the dimensions and weight requirements of the application. By recording block weights before dispatch, businesses can improve transaction transparency, support accurate billing, and reduce disagreements between suppliers and customers. On-site weighing also helps reduce trips to external public weighbridges solely for weight measurement, potentially saving transportation time and fuel. The supplied product information states that the system is approved by the Legal Metrology Department and designed to meet applicable SOLAS Verified Gross Mass (VGM) and NAHI requirements.

Specifications

Key Attributes
Product TypeGranite Block Weighing System
Weighing Capacity50,000 kg
Weighing Accuracy±10 kg
Display TypeDigital LED
Load Cell Capacity20,000 kg
Number of Load Cells4
Platform MaterialMild Steel
Platform Length6,000 mm
Power Supply230 V AC
Additional Information
Country of OriginIndia

Application

  1. Granite block weighing at quarry and extraction sites
  2. Truck load measurement at granite dispatch yards
  3. Weight verification for granite export shipments
  4. Block weight recording at stone processing facilities
  5. Supplier and customer weight reconciliation in granite trading

Shipping & Logistics

Company Profile

Invara Digitronics Private Limited
Invara Digitronics Private Limited, Karnataka
TruVerified
IndiaKarnataka, India
9 yrs
Manufacturer
Turn Over

₹5 Crore – ₹10 Crore

Factory Details
Factory SizeAbove 5000 sqm
Contract ManufacturingOEM Service
No. of Production Lines5
Frequently Asked Questions
1
What is a granite block weighing system used for?

A granite block weighing system is used to measure the weight of large granite blocks during processing, storage, transportation, and material handling operations.

2
How are granite blocks weighed using this system?

The system uses a suitable weighing platform or load cell arrangement to measure the applied load and display the corresponding weight value.

3
Where are granite block weighing systems commonly used?

These systems are used in granite quarries, stone processing units, mining operations, stone warehouses, and dimensional stone manufacturing facilities.

4
What factors should be considered when weighing heavy granite blocks?

Important factors include maximum load capacity, platform dimensions, load distribution, weighing accuracy, structural strength, and the method used to position the blocks.

Granite Block Weighing System

The Granite Block Weighing System is designed to measure granite block weights before loading, dispatch, and transportation. It provides a ready-to-use weighing solution to help stone businesses determine truck loading quantities and maintain transparent weight records. The system is available in different sizes and capacities to suit operational requirements. According to the supplied information, it is approved by the Legal Metrology Department and designed to address applicable SOLAS Verified Gross Mass (VGM) and NAHI requirements, subject to verification of the relevant approvals and regulations.

Min. Order Quantity: 1 Unit
