The MLX M Microscope by Magnus is a high-quality, student-friendly binocular microscope used for clear and detailed viewing of slides. It is designed with coated optics, coarse and fine focus, and LED illumination, making it reliable for regular lab.
HWF 10x (FN 18mm) eyepiece. The unique optical design of the compensating eyepiece provides relief from eye fatigue and renders color-compensated wide-field images of utmost clarify.
Condenser :
Abbe condenser with aperture its diaphragm (N.A.1.25) focusable with rack & pinion and a continuously variable iris diaphragm with a removable blue filter for daylight observation. Rack & pinion mounted condenser holder.
Focusing :
Coaxial coarse & fine controls with a focus adjustment and fine adjustment knobs. Coarse focus range 20mm.
Illumination base with option :
Built – in – illumination base with pre-centered 6V 20W halogen light source coupled with an efficient collector lenssystem. Transformer base power supply 100V – 240 AC 50/60Hz single phase. Supplied with one bulb & one spare fuse. Easily replaced lamp from front.
Illumination base with option :
LED light source high brightness,long life (30000 hrs).
Illumination base with option :
Led light source (with battery backup) High brightness,long life (30000 hrs). Battery backup in-built NiMH rechargeable batteries provide 6-8 hours back-up on full charge.
