A 1 HP LH openwell submersible pump provides an ideal pumping solution for scenarios requiring rapid water displacement over shorter vertical distances. Built with a sturdy cast iron body and high-conductivity copper motor windings, it operates quietly while fully submerged at the bottom of a water collection pit or well. The Low Head (LH) design utilizes wider impeller passages to maximize volumetric flow rate, enabling fast tank filling and efficient water circulation without overloading the motor. Because the entire pump assembly remains under liquid, it eliminates suction loss, avoids manual priming hassle, and benefits from continuous water cooling. This makes it a reliable, energy-efficient choice for residential buildings, agricultural nurseries, construction dewatering, and light industrial process tanks.
| Key Attributes | |
|---|---|
| Power Rating | 1 HP (0.75 kW) |
| Model Variant | Low Head (LH) High Discharge |
| Operating Voltage | 180 V to 240 V (Single Phase) |
| Max Discharge Head | 6 meters to 18 meters |
| Flow Rate Capacity | 200 LPM to 500 LPM |
| Pump Body Material | Cast Iron / Stainless Steel Frame |
| Impeller Material | High-Grade Bronze / Noryl |
| Additional Information | |
|---|---|
| Country of Origin | India |
Rapidly transfers high volumes of water from low-depth open wells and sumps to ground-level reservoirs.
Facilitates quick filling of overhead water storage tanks in domestic residential settings.
Powers low-pressure flood irrigation and garden watering systems in agricultural nurseries.
Dewaters shallow flooded basements, construction trenches, and open rain pits quickly.
Maintains water circulation in industrial washing stations, cooling sumps, and decorative fountains.
| Available Stock | In Stock |
| Sample Availability | No |
| Payment Terms |
|
| Payment Methods |
|
Tamil Nadu, IndiaLH stands for Low Head, indicating the pump is designed to deliver high discharge volume at lower vertical pumping heights.
LH pumps prioritize higher water volume (flow rate) over shorter vertical distances, whereas HH pumps deliver water to greater heights at lower flow rates.
No, because the pump is completely submerged in water, air locks are naturally eliminated, making it self-priming.
Yes, it operates on a standard single-phase 220V/240V power supply with normal domestic voltage tolerance.
Yes, continuous submersion in water keeps the motor cool, and internal water/oil motor filling further protects the copper windings from thermal stress.
